Hoogtes verkrijgbaar (H) 200, 300, 400, 500, 600, 700, 900 mm
Lengten verkrijgbaar (L) 400, 500, 600, 700, 800, 900, 1000, 1100, 1200, 1400, 1600, 1800, 2000, 2300, 2600, 3000 mm

Diepte (B):
- Type 10 47 mm
- Type 11 63 mm
- Type 20 66 mm
- Type 21 66 mm
- Type 22 100 mm
- Type 33 155 mm

- Connecting pitch h = H - 54 mm
- Connecting thread 4 × G½ inside
- Highest allowed working pressure 10 bar
- Highest allowed working temperature (°C) 110 °C
- Radiator connection left or right side
- Pressure Loss The pressure loss of the radiator for the respective working conditions can be calculated by means of the value of the flow coefficient AT or the resistance coefficient ?T

Voor meer informatie: Korado Radik Klasik
